What are the precautions for the installation of planetary reducers?

Author: Shenzhen Shunli Motor Co., Ltd.Time:2018-10-31 09:54:13Pageviews:2026smallmidbig

What are the precautions for the installation of planetary reducers? The following Shunli motor small series to give you a detailed introduction. First, it is strictly prohibited to hammer When...

What are the precautions for the installation of planetary reducers? The following Shunli motor small series to give you a detailed introduction.


First, it is strictly prohibited to hammer
When the output shaft of the planetary reducer is attached, the coupling, the pulley, the sprocket and other joints cannot be directly hammered. Because the output shaft structure of the planetary reducer cannot bear the axial hammer, the shaft end can be used. Screw in the screw and press into the coupling.


Planetary reducer


Second, must install a ventilation cap (exhaust screw plug)
Before use, replace the blockage at the highest position with the vent plug to ensure that the gas is discharged from the body when the reducer is running. If it is not replaced in time, the planetary reducer will run for a long time, causing the gas in the reducer to swell and collapse, and the reducer will leak oil.


Third, timely replacement of lubricants, pay special attention to the first time
Special attention should be paid to the first oil change. The planetary reducer should change the lubricating oil in time after the first 300-400 hours of operation, and then change the lubricating oil every 1500~2000 hours. In addition, in the working environment with harsh working environment, high temperature and high dust, the lubricating oil should be inspected every half month. It is found that the lubricating oil has dirt, that is, the lubricating oil is replaced to keep the lubricating oil clean and prolong the use of the reducer. Life expectancy and economic efficiency. Replacing the lubricant means: all the previous lubricants are drained, rinsed, and re-added.


The above is the introduction of the attention of the planetary reducer installation, I hope to bring help to friends in need, if you want to know more about the planetary reducer, please continue to pay attention to the Shunli motor.
